Product Details:
Payment & Shipping Terms:
|
| Name: | Gas Regulator | Application: | Gas Control System |
|---|---|---|---|
| Material: | Forge Copper | Color: | Yellow |
| Medium: | Argon/CO2 | ||
| High Light: | Medical Gas System In Hospitals,medical gas equipment |
||
Female 0.96''-14 Argon gas welding regulator 2 gauge single stage Forged copper for shielded arc
Specification:
|
P/N: PL-02
|
|
Properties: Gas system parts
|
|
Type: Argon gas regulator
|
|
Medium: Argon/CO2
|
|
Inlet thread: 0.96''-14 ( G5/8 female)
|
|
Outlet thread: G3/8 male
|
|
Outlet pressure: 0-0.6Mpa
|
|
Outlet Flux: 0~30L/min
|
|
Material: Forged copper
|
Description:
1. This regulator was designed for industrial manufacture,laboratory, MIG,TIG ,etc ,use for gas shielded arc welding
2. The regulator used single-stage decompress structure
3. The body was made by high quality forged copper
4. The cap was made by high strength Zinc Alloy and with chrome plated
5. Intake pipe with sintered bronze filter
6. 2’’ Pressure gauge
7. The flow tupe was made by shock resistance composite material, safe and durable
