Portable blood pressure simulator NIBP simulator medical simulator 9 sets of simulation values
Introduction:
The NIBP Blood Pressure Simulator is a high-accuracy medical test instrument engineered for comprehensive calibration, performance verification, and quality control of non-invasive blood pressure (NIBP) monitoring devices across diverse clinical environments. Designed as a professional-grade reference standard, this advanced simulator generates precise, repeatable physiological pressure waveforms that emulate real patient conditions, enabling biomedical engineers and clinical technicians to validate NIBP monitor accuracy, assess algorithm performance, and ensure compliance with international medical device standards (IEC 60601-2-27, ISO 81060-2). Featuring dual-channel invasive blood pressure (IBP) simulation capability alongside comprehensive NIBP simulation modes—including standard adult, pediatric, neonatal, arrhythmia, respiratory interference, and wrist-type blood pressure scenarios—this versatile instrument supports both static pressure calibration and dynamic waveform analysis. The simulator's programmable pressure range (0–300 mmHg for both systolic and diastolic) with user-defined custom settings enables thorough testing across the full clinical measurement spectrum. Integrated automated test sequences for pressure leak verification, over-pressure relief validation, and multi-condition BP simulation streamline preventive maintenance workflows while ensuring traceable calibration results.
Feature:
Dynamic blood pressure simulation for arm and wrist cuff monitors
Built-in air pump: For high/low-pressure deflation checks, leak tests, and pressure generation
Built-in sealed chambers: Allows direct testing of non-invasive blood pressure (NIBP) monitors without connecting an external cuff
High-precision pressure sensor ensures accurate readings
Pressure calibration function for blood pressure instruments
Compact, portable design with built-in sealed chambers for neonatal and adult testing
2.8-inch color display with button controls
Optional built-in 4-cell 18650 lithium battery pack for extended continuous operation
Capable of performing multiple blood pressure measurements
Includes an external power adapter
Includes a three-way connector, various reducing straight connectors, and tubing for blood pressure monitor testing
Built-in sealed chambers for neonatal and adult testing
Technical Specifications
Measurement Range: (0–60) kPa
Accuracy Class: ±0.1% F.S.
Absolute Error: <0.5 mmHg (0–300 mmHg)
Static Pressure: 0 mmHg to 450 mmHg
Pressure Source: Generates 20–410 mmHg pressure
Pressure Test: Static pressure at port: 0–450 mmHg
Pressure Resolution: 0.1 mmHg
Pulse Rate Range: 30 bpm–250 bpm
Pulse Amplitude: 0.1 cc–1.40 cc
Leak Rate: ≤0.4 mmHg/min (at 500 mL volume, 300 mmHg)≤1 mmHg/min (at 100 mL volume, 300 mmHg)
Standard Blood Pressure Simulation Values (Dynamic Simulation)
BP: 30/10 (16) Pulse: 80
BP: 50/30 (36) Pulse: 80
BP: 60/30 (40) Pulse: 80
BP: 80/50 (60) Pulse: 80
BP: 100/65 (76) Pulse: 80
