Name: | M1943A SpO2 Adapter Cable | Application: | Patient Monitor |
---|---|---|---|
Material: | TPU Cable | Color: | Grey/Blue |
Feature: | Compatible And New | ||
High Light: | spo2 extension cable,Medical Spare Parts |
Compatible M1943A SpO2 adapter cable 8 feet M1943A SpO2 extension cable TPU cable
Description:
The compatible M1943A SpO2 adapter cable connect with reusable or disposable SpO2 sensor work with : Medical: Heartstream XL, Intelliview MP70, M2601A, M3000A, M3500B, M4735A, M1020B, M3000A/M3001A MMS, M3002A MMS X2, M8102A MP2, M8105A MP5, SureSigns VS2, VS3.
OEM reference P/N:
M1943A (1.1 meters)
M1943AL (3 meters)
989803128651 (3 meters)
Specification:
OEM P/N: M1943A
|
Connector: 8 pin male <> DB 9 pin female
|
Connect sensor type : sensor with Non-Oximax technology
|
Material: TPU cable, gold plated pin
|
Length: 2.4 meter
|
Packing: 1 piece per pack
|
MOQ: 1 piece
|
Warranty: 1 year
|
OEM service: Available
|
Delivery date: 1 to 7 days
|
Biocompatibility:All patient contact materials are latex free and have been tested according to ISO 10993-5, ISO 10993-10
|
Storage and Transport Environment: -10°C~+40°C
|
Operating Temperature: +5°C~+40°C
|
How to use the SpO2 adapter cable:
With the SpO2 adapter cable you can replace the sensor with reusable or disposable one, and it can change with different patient type SpO2 sensor, such as adult finger clip,Pediatric finger clip, Neonate foot wrap, Adult ear clip sensor... ...etc. You just realized it with only one SpO2 adater cable. One side connect to the patient monitor side, another side connect to the SpO2 sensor you use.
Advance:
Replacement SpO2 adapter cable with high quality compare to original up 95%~100%,but with reasonable cost save price about 10%~30% compare to original.
Help you save the additional cost with acceptable high quality. No need a huge budget for a new original.
Note: All brands name above for reference only!
